Appendices
B-2
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
B-1 V430-F Input and Output Modules
There are 7 Input Modules and 2 Output Modules. The layout of each module and the definitions of the
data in them will be shown in this appendix.
Additional Information
The maximum Input CR size for the PNT21 is 450 bytes.
All Input/Output modules and module descriptions are the same as in Appendix A, except the following
new addition: Omron Decode Input Module.
 Omron Decode Input ID:106
Total Size: 442 Bytes
B-1-1 Module Types
Model Item ID Name Total Size in Bytes PNT21 Supported
100 Small Legacy Input Module 84 Yes
101 Big Legacy Input Module 176 Yes
102
MXL Input Module
248 Yes
103 1 Decode Input Module 500 No
104 4 Decode Input Module 500 No
105 N Decode Input Module 500 No
106 Omron Decode Input Module 442 Yes
197 Premier Output Module 4Yes
198 Legacy Output Module 12 Yes
Input/Output Modules
SHORT DESCRIPTION SIZE (BYTES)
INFO BITS 1
DIAGNOSTIC SEQUENCE COUNT 1
RESERVED 1
RESERVED 1
DEVICE STATUS 4
FAULT 4
COUNTERS 24
READ CYCLE REPORT 8
DECODE CYCLE REPORT 16
DECODE DATA LENGTH
4
DECODE DATA STRING
378
