Click on the Format: text in blue below Format Output to open the Output Formatting Editor.
3 Parse Symbol? Check this box.
Press the appropriate button to select either Extract chars from symbol data, or Insert
your own text.
4 If you want to specify the range (number) of characters from the read character string to output,
select Extract chars from symbol data.
Enter the range for the number of characters to output. In the example setting below, a string
length of 1 to 4 characters is output.
To apply this setting, click the button.
5 If you want to insert a fixed character string in to the read (decoded) character string to output,
select Insert your own text.
3 Controlling Operation and Data Output with Ethernet
3 - 34
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
