Omron V430-F Series User Manual For Communication Settings

4-1
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
4
This section describes the procedures for connecting the V430-F Series Reader to the
NJ
Series Machine Automation Controller (hereinafter referred to as Controller) via
Profinet IO), and for verifying the device connections. After following the configurations
in this section, the user will be able to view PROFINET input and output module data,
make changes to the output module, and verify those changes at the input module. The
examples in this section do not contain any PLC programming, custom data structures,
or setup, beyond connecting the input and output modules. It is the user’s responsibility
to program the controller once data access to the V430-F has been established.
4-1 Overview of PROFINET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4-1-1 Types of PROFINET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4-
2 V430-F Communications for PROFINET Connections . . . . . . . . . . . . . . . . .4-6
4-2-1 Types of Communication Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4-3 Setting Up PROFINET Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4-3-1
Configuring Network Settings in the V430-F . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7
4-3-2
Timing Charts by Module Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Controlling Operation and Data
Output with PROFINET

Omron V430-F Series Specifications

General

Brand	Omron
Model	V430-F Series
Category	Barcode Reader
Language	English
