4 Controlling Operation and Data Output with PROFINET
4-4
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
PROFINET IO specifies the supported functions by conformance class, with consideration
given to the application.
The functions below are defined in Class A.
The functions below are defined in Class B, which expands upon Class A.
The devices below are defined in PROFINET IO.
Class Overview
V430-F Support
Class A
Supports the basic functions of RT
communication.
Supported
Class B
This class adds network diagnosis
and redundancy functions used in
process automation and other
applications.
Supported
Class C
Supports IRT communication that
realizes reliable synchronization.
Not Supported
Function Overview
Cyclic Data Exchange
Real-time data communication between the I/O
controller and I/O devices at determined cycles.
Set by I/O data CR.
Acyclic Parameter Data / Device Identification
Used for parameter settings, I/O device configuration,
and reading of device information. Set by record data CR.
Device / Network Diagnosis
Communication for the purpose of sending alarms and
statuses from I/O devices to the I/O controller. Set by
Alarm CR.
Function Overview
SNMP (Simple Network Management Protocol)
Allows additional Network Diagnostics via
Management Information Base 2 (MIB2) and Lower
Link Layer Discovery Protocol-MIB(LLDP-EXT-MIB).
PDEV (Physical Device Object)
Can also gather diagnostic information using acyclic
PROFINET services.
Device Types Used in PROFINET IO
Type Details
I/O Controller Controller for external and other devices.
I/O Device
Reader device connected to the I/O controller. The
V430-F is an I/O device.
I/O Supervisor PC or other device used for maintenance and diagnosis.
