Omron V680S Series User Manual

Section 5 EtherNet/IP Communications Protocol
Tag Data Link Setting Methods
This section describes how to set data links for EtherNet/IP.
The communications areas in the PLC for which data links are created to the Reader/Writer are
specified as tags and tag sets, and the connections are set for tag data link communications.
To connect to OMRON PLCs or Controllers, you use the Network Configurator to set up tag data links
(i.e., tags, tag sets, and connection settings).
Refer to the following manuals for details on the tag data link settings that are made with the Network
Configurator.
• NJ-series CPU Unit Built-in EtherNet/IP Port User´s Manual (Cat. No. W506)
• CS/CJ-series EtherNet/IP Units Operation Manual (Cat. No. W465)
• CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (Cat. No. W495)
To set tag data links, an EDS file that defines the V680S connection is required. Download the EDS file from the
OMRON website.
The communications areas in the PLC are set as tag data link connections as shown in the following
table.
 Tag and Tag Set Settings in the PLC
*1 Select one of the following values for the data size according to the data size required to write or
read an RF Tag in one operation.
Setting item
Setting
Command Area Response Area
Type of tags and tag set Output tag sets Input tag sets
Tag and tag set names I/O memory addresses or variable names I/O memory addresses or variable names
Data sizes 40, 264, 520, or 1,032 bytes
*1
40, 264, 520, or 1,032 bytes
*1
Data size
Data size that can be read or written
for an RF Tag in one operation
40 bytes 32 bytes
264 bytes 256 bytes
520 bytes 512 bytes
1,032 bytes 1,024 bytes
