Omron V680S Series User Manual

Section 5 V680S Command Details
GET OPERATING TIME
This command reads the operating time since the Reader/Writer was started.
The operating time is reset when the Reader/Writer is reset.
 Command Area
 Response Area
 Execution Example
Reading the Operating Time When It Is 1,234,567,890 (4996 02D2 hex)
Signal/data Data type Size Function
CmdCode/Command Code WORD 2 bytes 2002 hex
CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.)
CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.)
Signal/data Data type Size Function
ErrCode/Error code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes 0000 hex (Not used.)
RespInfo2/Response Information 2 WORD 2 bytes 0000 hex (Not used.)
RespData/Response Data
Operating time
UDINT 4 bytes
Running time since the Reader/Writer was started (in
milliseconds)
0000 0000 to FFFF FFFF hex
bit15-12 bit11-8 bit7-4 bit3-0
2
002
0
000
0000
CmdCode
CmdParam1
CmdParam2
Data name
+1
+2
+3
Memory offset
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
0
2D2
4996
RespData[0-1]
RespData[2-3]
+4
+5
Command Area Response Area
