Omron V680S Series User Manual

Section 5 EtherNet/IP Communications Protocol
V680S Commands
 Command Codes
The following table lists the command codes that you can specify for execution by the Reader/Writer.
Set these codes in the Command Code field in the command area.
 Error Codes
The following tables list the error codes that indicate the response results from the Reader/Writer.
These codes are set in the Error Code field in the response area.
If an error response is returned (i.e., an error code other than 0000 hex), a record is stored in the
command error log in the Reader/Writer. Records are not stored for errors for which responses are not
returned to the host device. Reader/Writer operating errors and system errors are recorded in the
system error log in the Reader/Writer.
 Normal Code
 Interrupted Processing
Classification Command code Command name Reference
RF Tag communications 0001 hex READ ID Refer to page 115.
0002 hex READ DATA Refer to page 116.
0003 hex WRITE DATA Refer to page 117.
0004 hex LOCK Refer to page 119.
0005 hex DATA FILL Refer to page 118.
0006 hex RF TAG OVERWRITE COUNT CONTROL Refer to page 120.
0007 hex RESTORE DATA Refer to page 121.
0008 hex COPY DATA Refer to page 122.
Reader/Writer settings
1000 hex
INITIALIZE Refer to page 124.
1001 hex
SET RF TAG COMMUNICATIONS Refer to page 125.
1002 hex
GET RF TAG COMMUNICATIONS SETTINGS Refer to page 126.
1003 hex SET MULTI-READER/WRITER OPERATION Refer to page 127.
1004 hex GET MULTI-READER/WRITER SETTINGS Refer to page 129.
Reader/Writer information
acquisition
2000 hex GET MODEL INFORMATION Refer to page 131.
2001 hex GET FIRMWARE VERSION Refer to page 132.
2002 hex GET OPERATING TIME Refer to page 133.
2003 hex MEASURE NOISE Refer to page 134.
2004 hex GET COMMAND ERROR LOG Refer to page 137.
2005 hex GET RESTORE INFORMATION Refer to page 135.
2006 hex GET MULTI-READER/WRITER STATUS Refer to page 139.
Reader/Writer operation
control
3000 hex
RESET Refer to page 140.
Error code name Error code Description
Normal end 0000 hex Processing ended normally.
Error code name Error code Description
Communications canceled
0001 hex
Processing was canceled when an OFF EXE signal was received before
an RF Tag was detected. (The contents of the RF Tag was not changed,
even for a WRITE DATA command.)
Communications aborted
0002 hex
Processing was canceled when an OFF EXE signal was received during
communications with an RF Tag. (For a WRITE DATA command, the
contents of the RF Tag may have been changed.)
