Omron V680S Series User Manual

Section 5 V680S Command Details
READ DATA
This command reads data from the RF Tag in the communications field.
 Command Area
 Response Area
 Execution Example
Reading Four Words of Data Starting from Word Address 1234 Hex in the RF Tag
Signal/data Data type Size Function
CmdCode/Command Code WORD 2 bytes 0002 hex
CmdParam1/Command Parameter 1
WORD 2 bytes
First word address of the data read from the RF Tag
0000 to FFFF hex
CmdParam2/Command Parameter 2
WORD 2 bytes
The maximum data size that you can read from an RF
Tag depends on the data size setting (in words).
0000 to 0200 hex
* The maximum size that you can specify depends on
the tag data link settings.
Signal/data Data type Size Function
ErrCode/Error Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes Error device information
RespInfo2/Response Information 2 WORD 2 bytes Communications diagnostics result
RespData/Response Data
Read data ARRAY[]
OF BYTE
1,024 bytes
max.
Data read from the RF Tag
bit15-12 bit11-8 bit7-4 bit3-0
0
002
1
234
0004
CmdCode
CmdParam1
CmdParam2
Data name
+1
+2
+3
Memory offset
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
1
111
2
222
RespData[0-1]
RespData[2-3]
+4
+5
3
333
4444
RespData[4-5]
RespData[6-7]
+6
+7
Command Area Response Area
bit15-12 bit11-8 bit7-4 bit3-0
1
111
2
222
3333
1234
Hex
1235Hex
1236Hex
User address
44441235Hex
RF Tag Memory
