Section 8 Product Specifications
Product Specifications
Reader/Writer
General Specifications
Item Model V680S-HMD63-EIP V680S-HMD64-EIP V680S-HMD66-EIP
Compliance standards
ISO/IEC 18000-3 (15693)
Frequency 13.56 MHz
Dimensions 50 50 30 mm (W H D,
excluding protruding parts and
cables)
75 75 40 mm (W H D,
excluding protruding parts and
cables)
120 120 40 mm (W H D,
excluding protruding parts and
cables)
Power supply voltage 24 VDC (-15% to +10%)
Consumption current 0.2A max.
Ambient operating
temperature
-10 to 55C (with no icing)
Ambient operating
humidity
25% to 85% (with no condensation)
Ambient storage
temperature
-25 to 70C (with no icing)
Ambient storage
humidity
25% to 85% (with no condensation)
Insulation resistance 20 M min. (at 500 VDC) between cable terminals and case
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min between cable terminals and case
Vibration resistance No abnormality after application of 10 to 500 Hz, 1.5-mm double amplitude, acceleration: 100 m/s
2
, 10
sweeps in each of 3 axis directions (up/down, left/right, and forward/backward) for 11 minutes each
Shock resistance No abnormality after application of 500 m/s
2
, 3 times each in 6 directions (Total: 18 times)
Degree of protection IP67 (IEC 60529:2001)
Oil resistance equivalent to IP67F (JIS C 0920:2003, Appendix 1)
See Note 1
Materials Case: PBT resin, Filled resin: Urethane resin
Mass Approx. 240 g Approx. 390 g Approx. 760 g
Installation method Reader/Writer body: Two M4
screws (Use a screw of 12 mm
or more in length.)
Cable branching section: One
M4 screw
Four M4 screws
Use a screw of 12mm or more in length.
Host communications
interface
Ethernet 10BASE-T/100BASE-TX
Host device
communications
protocol
EtherNet/IP
Accessories Instruction Sheet
Copy of EC Self Declaration
IP address label
Note 1. Oil resistance has been tested using a specific oil as defined in the OMRON test method.
