Omron V680S Series User Manual

Section 5 V680S Command Details
GET RF TAG COMMUNICATIONS SETTINGS
This command reads the RF Tags communications conditions from the Reader/Writer
(communications option, communications speed, and write verification).
 Command Area
 Response Area
 Execution Example
Reading the Communications Settings When the Communications Option Is Set to Repeat, the
Communications Speed Is Set to Standard, Write Verification Is Disabled, and Communications
Diagnostics Are Enabled
Signal/data Data type Size Function
CmdCode/Command Code WORD 2 bytes 1002 hex
CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.)
CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.)
Signal/data Data type Size Function
ErrCode/Error Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes 0000 hex (Not used.)
RespInfo2/Response Information 2 WORD 2 bytes 0000 hex (Not used.)
RespData/Response Data
Communications Option
WORD 2 bytes
0000 hex: Once
0001 hex: Repeat
0002 hex: FIFO Repeat
Communications Speed
WORD 2 bytes
0000 hex: High speed
0001 hex: Normal speed
Write Verification
WORD 2 bytes
0000 hex: Do not verify.
0001 hex: Verify
Communications Diagnostics
WORD 2 bytes
0000 hex: Disable
0001 hex: Enable
bit15-12 bit11-8 bit7-4 bit3-0
1
002
0
000
0000
CmdCode
CmdParam1
CmdParam2
Data name
+1
+2
+3
Memory offset
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
0
001
0
001
RespData[0-1]
RespData[2-3]
+4
+5
0
000
0001
RespData[4-5]
RespData[6-7]
+6
+7
Command Area Response Area
