Omron V680S Series User Manual

Section 5 V680S Command Details
DATA FILL
This command fills the specified number of words in the RF Tag in the communications field with the
specified data.
 Command Area
 Response Area
 Execution Example
Writing 5A5A Hex to Four Words Starting from Word Address 1234 Hex in the RF Tag
Signal/data Data type Size Function
CmdCode/Command Code WORD 2 bytes 0005 hex
CmdParam1/Command Parameter 1
WORD 2 bytes
First word address of the data to write to the RF Tag
0000 to FFFF hex
CmdParam2/Command Parameter 2
WORD 2 bytes
Number of words in the RF Tag to write
0000 hex: Specifies the entire area.
0001 to FFFF hex: Specified size
CmdData/Command Data
Fill data ARRAY[]
OF BYTE
2 bytes
Fill data to write to the RF Tag (always one word)
Signal/data Data type Size Function
ErrCode/Error Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes Device information
RespInfo2/Response Information 2 WORD 2 bytes Communications diagnostics result
CmdCode
CmdParam1
CmdParam2
Data name
+1
Memory offset
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
Command Area Response Area
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
bit15-12 bit11-8 bit7-4 bit3-0
0
005
1
234
0004
5A5ACmdData[0-1]
+2
+3
+4
bit15-12 bit11-8 bit7-4 bit3-0
5
A5A
5
A5A
5A5A
1234
Hex
1235Hex
1236Hex
User address
5A5A1235Hex
RF Tag Memory
