Section 5 V680S Command Details
GET MULTI-READER/WRITER STATUS
This command reads the Master Reader/Writer and Slave Reader/Writer status when multi-Reader/
Writer operation is being used.
 Command Area
 Response Area
 Execution Example
Reading the Multi-Reader/Writer Status When the Reader/Writer Is in Field Extension Mode, the
Group Is Being Detected, Connection of Slave Reader/Writer No. 2 Failed, and Slave Reader/Writers
No. 3 to 7 Are Not Connected
Signal/data Data type Size Description
CmdCode/Command Code WORD 2 bytes 2006 hex
CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.)
CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.)
Signal/data Data type Size Description
ErrCode/Error Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes 0000 hex (Not used.)
RespInfo2/Response Information 2 WORD 2 bytes 0000 hex (Not used.)
RespData/Response Data
Master Status
WORD 2 bytes
Multi-Reader/Writer status of Master Reader/Writer
0000 hex: Disable
1000 hex: Preparing for Field Extension Mode
(Detecting Groups)
1001 hex: Ready for Field Extension Mode (Group
Detection Completed)
2000 hex: Preparing for High-speed Traveling Mode
(Detecting Groups)
2001 hex: Ready for High-speed Traveling Mode
(Group Detection Completed)
Slave No. 1 Status
WORD 2 bytes
Connection status of Slave Reader/Writers No. 1 to 7
0000 hex: Not connected.
0001 hex: Connection successful
0002 hex: Connection failed
:
::
Slave No. 7 Status
WORD 2 bytes
bit15-12 bit11-8 bit7-4 bit3-0
2
006
0
000
0000
CmdCode
CmdParam1
CmdParam2
Data name
+1
+2
+3
Memory offset
Command Area
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
Response Area
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
1
000
0
001
0
002
0000
0 000
0
000
0
000
0000
RespData[0-1]
RespData[2-3]
RespData[4-5]
RespData[6-7]
RespData[8-9]
RespData[10-11]
RespData[12-13]
RespData[14-15]
+4
+5
+6
+7
+8
+9
+10
+11
Master Reader/Writer
Slave Reader/Writer No. 5
Slave Reader/Writer No. 6
Slave Reader/Writer No. 7
Slave Reader/Writer No. 1
Slave Reader/Writer No. 2
Slave Reader/Writer No. 3
Slave Reader/Writer No. 4
