Section 5 V680S Command Details
GET MODEL INFORMATION
This command reads the model of the Reader/Writer.
 Command Area
 Response Area
 Execution Example
Reading the Model When a V680S-HMD63-EIP Reader/Writer Is Being Used
Signal/data Data type Size Function
CmdCode/Command Code WORD 2 bytes 2000 hex
CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.)
CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.)
Signal/data Data type Size Function
ErrCode/Error Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes 0000 hex (Not used.)
RespInfo2/Response Information 2 WORD 2 bytes 0000 hex (Not used.)
RespData/Response Data
Model Number Information ARRAY[]
OF BYTE
32 bytes
32 bytes of ASCII text max. (end code: 0000 hex)
bit15-12 bit11-8 bit7-4 bit3-0
2
000
0
000
0000
CmdCode
CmdParam1
CmdParam2
Data name
+1
+2
+3
Memory offset
Command Area
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
Response Area
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
3
656
3
038
2
D53
4D48
3 644
2
D33
4
945
0050
0 000
0000
0 000
0
000
0
000
0000
0 000
0000
RespData[0-1]
RespData[2-3]
RespData[4-5]
RespData[6-7]
RespData[8-9]
RespData[10-11]
RespData[12-13]
RespData[14-15]
RespData[16-17]
RespData[18-19]
RespData[20-21]
RespData[22-23]
RespData[24-25]
RespData[26-27]
RespData[28-29]
RespData[30-31]
+4
+5
+6
+7
+8
+9
+10
+11
+12
+13
+14
+15
+16
+17
+18
+19
Model number information obtained from Reader/Writer
