Omron V680S Series User Manual

Section 5 V680S Command Details
GET RESTORE INFORMATION
This command reads the restore information from memory in the Reader/Writer.
The restore information is reset when the Reader/Writer is reset.
 Command Area
 Response Area
* The maximum size of the response data depends on the tag and tag set settings. Therefore, the
number of records of restore information that can be read with one operation will vary. A parameter
error will occur if the setting exceeds the response data size.
Signal/data Data type Size Function
CmdCode/Command Code WORD 2 bytes 2005 hex
CmdParam1/Command Parameter 1
WORD 2 bytes
Number of first record to read
0000 to 0007 hex (0 to 7)
CmdParam2/Command Parameter 2
WORD 2 bytes
Number of records to read
0001 to 008 hex (1 to 8)
* The maximum number of records that you can specify
depends on the tag data link settings.
Signal/data Data type Size Function
ErrCode/Error Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes 0000 hex (Not used.)
RespInfo2/Response Information 2 WORD 2 bytes 0000 hex (Not used.)
RespData/Response Data
Number of Records
UINT 2 bytes
Number of valid records in the restore information
0000 to 0008 hex (1 to 8)
Newest Record Operating Time
UDINT 4 bytes
Operating time in milliseconds when RF Tag data lost
error occurred
0000 0000 to FFFF FFFF hex
RF Tag ID ARRAY[]
OF BYTE
8 bytes
UID of the RF Tag when the RF Tag data lost error
occurred
User Address
WORD 2 bytes
First write address when an RF Tag data lost error
occurred
Data Size
WORD 2 bytes
Write size when an RF Tag data lost error occurred
Data BYTE[]
OF BYTE
8 bytes
Data in the RF Tag before the write operation when the
RF Tag data lost error occurred
Newest Record
- 1
Same as
above.
Same as
above.
Same as
above.
Same as above.
;:
::
:
Newest Record
- 7
Same as
above.
Same as
above.
Same as
above.
Same as above.
