Omron V680S Series User Manual

Section 5 V680S Command Details
V680S Command Details
READ ID
This command reads the ID code of the RF Tag in the communications field.
 Command Area
 Response Area
 Execution Example
Reading the ID Code of the RF Tag
Signal/data Data type Size Description
CmdCode/Command Code WORD 2 bytes 0001 hex
CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.)
CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.)
Signal/data Data type Size Description
ErrCode/Error Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes Device information
RespInfo2/Response Information 2 WORD 2 bytes Communications diagnostics result
RespData/Response Data STRUCT - -
ID Data ARRAY[]
OF BYTE
8 bytes
UID data read from the RF Tag (always 8 bytes)
bit15-12 bit11-8 bit7-4 bit3-0
0
001
0
000
0000
CmdCode
CmdParam1
CmdParam2
Data name
+1
+2
+3
Memory offset
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
5
566
3
344
RespData[0-1]
RespData[2-3]
+4
+5
1
122
E005
RespData[4-5]
RespData[6-7]
+6
+7
66554433221105E0
RF Tag UID
Command Area Response Area
