Omron V680S Series User Manual

Section 5 EtherNet/IP Communications Protocol
 System Errors
 Device Information
The following table lists the device information that indicates the Reader/Writer in which the error
occurred.
These codes are set in the Response Information 1 field in the response area.
 Communications Diagnostics Results
The following table lists the communications diagnostic results that are obtained when the Reader/
Writer communicates with an RF Tag.
If communications diagnostics are enabled, these codes are provided to indicate the cause when
diagnostics indicate that communications are unstable.
This information is set in the Response Information 2 field in the response area. When this information
is set, the RF_WAR (communications unstable) signal turns ON.
Error code name Error code Description
System startup errors
System memory error
F001 hex
An error was detected in system memory. A record is stored only in the
system error log.
Profile error
F002 hex
An error was detected in the profile data. A record is stored only in the
system error log.
Hardware faults
IC error F011 hex An error was detected in an IC in the Reader/Writer.
Configuration memory
error
F012 hex
An error was detected when accessing configuration memory.
Device information Description
0000 hex An error occurred in the local Reader/Writer.
0100 hex • An error occurred in the destination Reader/Writer when copying data.
• An error occurred in Slave Reader/Writer No. 1 for multi-Reader/Writer operation.
0200 hex An error occurred in Slave Reader/Writer No. 2 for multi-Reader/Writer operation.
0300 hex An error occurred in Slave Reader/Writer No. 3 for multi-Reader/Writer operation.
0400 hex An error occurred in Slave Reader/Writer No. 4 for multi-Reader/Writer operation.
0500 hex An error occurred in Slave Reader/Writer No. 5 for multi-Reader/Writer operation.
0600 hex An error occurred in Slave Reader/Writer No. 6 for multi-Reader/Writer operation.
0700 hex An error occurred in Slave Reader/Writer No. 7 for multi-Reader/Writer operation.
Communications diagnostics
result
Description
0000 hex Normal
0001 hex Insufficient power to send
0002 hex Insufficient power to receive
0003 hex Too much noise
0004 hex Insufficient signal-to-noise ratio
