Omron V680S Series User Manual

Section 5 V680S Command Details
SET MULTI-READER/WRITER OPERATION
This command sets multi-Reader/Writer operation.
 Command Area
 Response Area
Signal/data Data type Size Function
CmdCode/Command Code WORD 2 bytes 1003 hex
CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.)
CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.)
RespData/Response Data
Multi-Reader/Writer Mode
WORD 2 bytes
0000 hex: Disable
0001 hex: Enable Field Extension Mode
0002 hex: Enable High-speed Traveling Mode
Number of Slave Reader/Writers
WORD 2 bytes
Number of Reader/Writers linked with multi-Reader/
Writer operation
0000 to 0007 hex
* Specify 0000 hex if multi-Reader/Writer operation is
disabled.
IP Address of Slave Reader/
Writer No. 1
DWORD 4 bytes
IP addresses of Slave Reader/Writers
0000 0000 to FFFF FFFF hex
Example: C0A801C8 hex (192.168.1.200)
* Specify 0000 0000 hex if multi-Reader/Writer
operation is disabled or the Slave Reader/Writer is not
used.
IP Address of Slave Reader/
Writer No. 2
DWORD 4 bytes
IP Address of Slave Reader/
Writer No. 3
DWORD 4 bytes
IP Address of Slave Reader/
Writer No. 4
DWORD 4 bytes
IP Address of Slave Reader/
Writer No. 5
DWORD 4 bytes
IP Address of Slave Reader/
Writer No. 6
DWORD 4 bytes
IP Address of Slave Reader/
Writer No. 7
DWORD 4 bytes
Signal/data Data type Size Function
ErrCode/Error Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes 0000 hex (Not used.)
RespInfo2/Response Information 2 WORD 2 bytes 0000 hex (Not used.)
