Omron V680S Series User Manual

Section 5 V680S Command Details
MEASURE NOISE
This command measures the noise level around the Reader/Writer.
 Command Area
 Response Area
 Execution Example
Measuring the Noise Level When the Average Level Is 51 (0033 Hex), the Maximum Level Is 62 (003E
ex), and the Minimum Level Is 41 (0029 Hex)
Signal/data Data type Size Function
CmdCode/Command Code WORD 2 bytes 2003 hex
CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.)
CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.)
Signal/data Data type Size Function
ErrCode/Error code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes 0000 hex (Not used.)
RespInfo2/Response Information 2 WORD 2 bytes 0000 hex (Not used.)
RespData/Response Data
Average Noise Level
UINT 2 bytes
0000 to 0063 hex (level 0 to 99)
Maximum Noise Level
UINT 2 bytes
0000 to 0063 hex (level 0 to 99)
Minimum Noise Level
UINT 2 bytes
0000 to 0063 hex (level 0 to 99)
bit15-12 bit11-8 bit7-4 bit3-0
2
003
0
000
0000
CmdCode
CmdParam1
CmdParam2
Data name
+1
+2
+3
Memory offset
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
0
033
0
03E
RespData[0-1]
RespData[2-3]
+4
+5
0029RespData[4-5]+6
Command Area Response Area
