Omron V680S Series User Manual

Section 5 V680S Command Details
SET RF TAG COMMUNICATIONS
This command sets the RF Tag communications conditions in the Reader/Writer (communications
option, communications speed, and write verification).
 Command Area
 Response Area
 Execution Example
Setting the Communications Option to Repeat, Setting the Communications Speed to Standard,
Disabling Write Verification, and Enabling Communications Diagnostics
Signal/data Data type Size Function
CmdCode/Command Code WORD 2 bytes 1001 hex
CmdParam1/Command Parameter 1 WORD 2 bytes 0000 hex (Not used.)
CmdParam2/Command Parameter 2 WORD 2 bytes 0000 hex (Not used.)
CmdData/Command Data
Communications Option
WORD 2 bytes
0000 hex: Once
0001 hex: Repeat
0002 hex: FIFO Repeat
Communications Speed
WORD 2 bytes
0000 hex: High speed
0001 hex: Normal speed
Write Verification
WORD 2 bytes
0000 hex: Do not verify.
0001 hex: Verify
Communications Diagnostics
WORD 2 bytes
0000 hex: Disable
0001 hex: Enable
Signal/data Data type Size Function
ErrCode/Error Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes 0000 hex (Not used.)
RespInfo2/Response Information 2 WORD 2 bytes 0000 hex (Not used.)
CmdCode
CmdParam1
CmdParam2
Data name
+1
Memory offset
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
Command Area Response Area
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
bit15-12 bit11-8 bit7-4 bit3-0
1
001
0
000
0000
0
001
0
001
CmdData[0-1]
CmdData[2-3]
0
000
0001
CmdData[4-5]
CmdData[6-7]
+2
+3
+4
+5
+6
+7
