Omron V680S Series User Manual

Section 5 V680S Command Details
WRITE DATA
This command writes data to the RF Tag in the communications field.
 Command Area
 Response Area
 Execution Example
Writing 1111222233334444 to Four Words Starting from Word Address 1234 Hex in the RF Tag
Signal/data Data type Size Function
CmdCode/Command Code WORD 16 bits WRITE DATA (0003 hex)
CmdParam1/Command Parameter 1
WORD 16 bits
First word address of the data to write to the RF Tag
0000 to FFFF hex
CmdParam2/Command Parameter 2
WORD 16 bits
The maximum data size that you can write to an RF Tag
depends on the data size setting (in words).
0000 to 0200 hex
* The maximum size that you can specify depends on
the tag data link settings.
CmdData/Command Data
Data to write ARRAY[]
OF WORD
1,024 bytes
max.
Data to write to RF Tag
Signal/data Data type Size Function
ErrCode/Response Code WORD 2 bytes Error code
RespInfo1/Response Information 1 WORD 2 bytes Error device information
RespInfo2/Response Information 2 WORD 2 bytes Communications diagnostics result
CmdCode
CmdParam1
CmdParam2
Data name
+1
Memory offset
ErrCode
RespInfo1
RespInfo2
Data name
+1
+2
+3
Memory offset
Command Area Response Area
bit15-12 bit11-8 bit7-4 bit3-0
0
000
0
000
0000
bit15-12 bit11-8 bit7-4 bit3-0
0
003
1
234
0004
1
111
2
222
CmdData[0-1]
CmdData[2-3]
3
333
4444
CmdData[4-5]
CmdData[6-7]
bit15-12 bit11-8 bit7-4 bit3-0
1
111
2
222
3333
1234
Hex
1235Hex
1236Hex
User address
44441235Hex
RF Tag Memory
+2
+3
+4
+5
+6
+7
