Omron V680S Series User Manual

Section 5 EtherNet/IP Communications Protocol
 Command Errors
 RF Tag Communications Errors
 Reader/Writer Operation Errors
Error code name Error code Description
Unknown command error 1003 hex A command that is not supported by the Reader/Writer was received.
Command parameter error 1005 hex There was an error in the parameters in the received command data.
Execution status error 1006 hex The Reader/Writer could not execute the command that was received.
Error code name Error code Description
RF Tag missing error 2001 hex There is no RF Tag in the communications field.
RF Tag communications error 2002 hex Communications with the RF Tag did not end normally.
UID mismatch error 2003 hex An RF Tag with the specified ID was not in the communications field.
RF Tag address error
2004 hex
The access address for the RF Tag is outside of the area supported by
the target RF Tag.
RF Tag lock error 2005 hex An attempt was made to write data to a locked area.
Verification error 2006 hex Processing to write data to the RF Tag did not end normally.
RF Tag data lost error
2007 hex
Processing to write data to the RF Tag did not end normally. (Data may
have been lost and must be restored.)
RF Tag system error 2008 hex The RF Tag returned an error response.
RF Tag overwriting error 2009 hex The overwrite limit was exceeded for overwrite count control processing.
Reader/Writer connection error
200A hex
When executing the COPY DATA command, communications could not
be established with the copy destination Reader/Writer.
Communications connection
error between Reader/Writers
200B hex
When executing multi-Reader/Writer functions, communications could
not be established with a Slave Reader/Writer.
Error code name Error code Description
Unfixed operation mode error
8001 hex
The control signal was not stable when the Reader/Writer was started. A
record is stored only in the system error log.
User setting error
8002 hex
An error was detected in user configuration memory when the Reader/
Writer was started. A record is stored only in the system error log.
The classification of the setting is given in attached information 1.
0000 0001 hex: Network setting
0000 0002 hex: RF Tag communications setting
0000 0003 hex: Multi-Reader/Writer setting
Multi-Reader/Writer execution
error
8003 hex
A set value was detected when the Reader/Writer was started that
prevents execution of multi-Reader/Writer operation.
The reason for the error is given in attached information 1.
0000 0001 hex: The combination of the Multi-Reader/Writer Mode and
the communications option prevented execution.
0000 0002 hex: This Reader/Writer has the same IP address as the
Slave Reader/Writer.
