Section 8
Product Specifications
V700-A80 Attachment
RF Tag Heat Resistance
•Storing RF Tags under high temperatures or under heat cycles will adversely affect the performance
of the internal parts and the service life of the RF Tags.
An LTPD of 10% was used for evaluation of RF Tags that reached the end of their service life after
testing under the following test conditions.
LTPD: Lot Tolerance Percent Defective
The lower limit of the malfunction rate for lots to be considered unacceptable during reliability testing.
Heat cycle: 1,000 cycles of 30 minutes each between -10 and 150C. No failures
occurred in 22 samples.
200 cycles of 30 minutes each between -10 and 180C. No failures
occurred in 22 samples.
High-temperature storage: 1,000 hours at 150C. No failures occurred in 22 samples.
200 hours at 180C. No failures occurred in 22 samples.
22
3.5
5
8
1
40
24
18
31±0.2
22
Two, 3.5 dia. mo
unting
holes
Two, 6 dia. countersinks
Two, M3 holes
Mounting Hole Dimensions
31±0.2
Materials PPS resin
(Unit: mm)
