Section 8 Product Specifications
Dimensions
V680S-D2KF67/-D2KF67M/-D8KF67/-D8KF67M
(Unit: mm)
Two, 3.5-dia.
mounting holes
32±0.2
40
32±0.2
40
32±0.2
32±0.2
Two, M3 holes
2
5
Mounting Hole Dimensions
Mounting height 5
+1
0
Case material PPS resin
