Section 8 Product Specifications
Dimensions
V680S-D2KF68/-D2KF68M/-D8KF68/-D8KF68M
Two, M4 holes
76±0.2
86
44±0.2
54
Two, 4.5-dia.
mounting holes
(Unit: mm)
5
Mounting Hole Dimensions
76±0.2
44±0.2
Mounting height 10
10
+1
0
Case material PPS resin
