Section 8 RF Tag Installation Precautions
V680-D8KF68A
Influence of Metal at Back Surface of RF Tags
The communications range will decrease if there is metal at the back of the V680-D1KP68A RF Tag. If
the RF Tag is mounted on metallic material, use a non-metallic spacer (e.g., plastic or resin). The
following graphs show the relationship between the distance from the RF Tag to the metallic surface
and the communications range.
0
10
20
30
40
50
60
70
80
90
100
50 100 150 (mm)
(%)
X
Y
0
10
20
30
40
50
60
70
80
90
100
50 100 150 (mm)
(%)
X
Y
Communications
range
Communications
range
Reader/Writer
RF Tag
Metal
Non-metallic material
Metal
Non-metallic material
Reader/Writer
RF Tag
Communications range (range with
no metal at back surface = 100%)
V680S-HMD64-EIP and V680-D8KF68A V680S-HMD66-EIP and V680-D8KF68A
Distance (x) to the metal plate in back of RF TagDistance (x) to the metal plate in back of RF Tag
Communications range (range with
no metal at back surface = 100%)
Metal on bac
k
Metal on back
