Omron V680S Series User Manual

Section 8
RF Tag Installation Precautions
V680S-D8KF67
 Influence of Metal at Back Surface of RF Tags
The communications range will decrease if there is metal at the back of the V680S-D8KF67 RF Tag. If
the RF Tag is mounted on metallic material, use a non-metallic spacer (e.g., plastic or resin). The
following graphs show the relationship between the distance from the RF Tag to the metallic surface
and the communications range.
Y
Communications
range
Reader/Writer
RF Tag
Metal
Non-metallic
material
Metal on back
V680S-HMD63-EIP and V680S-D8KF67
V680S-HMD66-EIP and V680S-D8KF67
Metal
Metal on bac
k
Reader/Writer
RF Tag
X
0
10
20
30
40
50
60
70
80
90
100
50 100 150 200
(mm)
(%)
X
X
0
10
20
30
40
50
60
70
80
90
100
100 200 300 350
(mm)
(%)
0
10
20
30
40
50
60
70
80
90
100
50 100 150 200
(mm)
(%)
Y
Communications
range
Y
Communications
range
Communications range (range with no metal at back surface = 100%)
Distance (x) to the metal plate in back of RF Tag
Communications range (range with no metal at back surface = 100%)
Distance (x) to the metal plate in back of RF Tag
Reader/Writer
RF Tag
Metal on back
Metal
Non-metallic
material
Non-metallic
material
V680S-HMD64-EIP and V680S-D8KF67
