Section 2 Functions
Network Settings
You can set the parameters for communications between the Reader/Writer and the host device. If you
change the settings, you must reset the Reader/Writer to enable the new settings.
IP Address, Subnet Mask, and Default Gateway
You can use any of the following methods to set the IP address, subnet mask, and default gateway for
the Reader/Writer.
If you select Obtain from BOOTP server as fixed settings, the settings will automatically be changed to fixed settings
after the IP address is obtained from the BOOTP server.
To stop obtaining the settings from the BOOTP server, select fixed settings and then manually set the IP address,
subnet mask, and gateway address.
If you use multi-Reader/Writer operation, do not change the IP address of a slave Reader/Writer directly. To change it,
change the multi-Reader/Writer settings on the master Reader/Writer.
Setting the Web Password
You can set a password for logging in from a Web interface. The password can be up to 15 ASCII
characters. No password is set by default.
If a Web password is set, a dialog box requesting entry of the password will be displayed when the
initial Web server interface is displayed. If the correct password is entered, the normal Web interface
can be used.
Setting method Description
Fixed settings You can set the IP address, subnet mask, and default gateway as required.
The default settings are as follows:
IP address: 192.168.1.200
Subnet mask: 255.255.255.0
Default gateway: 192.168.1.254
Obtain from BOOTP server The IP address, subnet mask, and default gateway are obtained from the BOOTP server every
time the power supply is turned ON.
Obtain from BOOTP server as
fixed settings
The IP address, subnet mask, and default gateway are obtained from the BOOTP server when
the power supply is turned ON and then they are used as fixed settings whenever the Reader/
Writer is started after that.
Ethernet
IP address
BOOTP command
Reader/Writer
BOOTP server
