Section 3 Installation
 V680-D1KP66T-SP
Mount the RF Tag using M5 screws and washers. The tightening torque is 1.2 N·m.
There are no restrictions on the mounting direction for the RF Tag or the direction of RF Tag travel in
respect to the Reader/Writer.
Refer to RF Tag Installation Precautions in Section 8 Appendices for information on the effect of metal at the back surface,
Mutual interference of RF Tags and Influence of Inclination of the V680-D1KP66T-SP.
p.237
Mounting Hole Dimensions
Two, M5 holes
80±0.2
