Chapter-11
Appendix
NLV-5201 User's Manual
144
1st
Item
Specification
Note
Environmental Specifications
Temperature
Operating
0 to 50 °C
Storage
-20 to 60 °C
Humidity
Operating
20 to 85% (no condensing, no frost)
Storage
20 to 90% (no condensing, no frost)
Ambient light
immunity
Fluorescent
10,000 lx or less
UPC/EAN 0.33 mm
Optical axis angle 75°
Distance
SR, HD: 125 mm
UD: 78mm
Sunlight
100,000 lx or less
Vibration
10 Hz to 100 Hz, acceleration of 19.6 m/s
2
, 60
minutes per cycle, repeat once in each X, Y and
Z-direction
Drop
Drop 3 times, at each 5 faces (right, left, front,
back and top), from a height of 75 cm onto a
concrete surface.
Excluding the part
where the interface
cable is attached
Dust and drip proof
IP65 equivalent
Physical
Features
Dimensions (mm)
Approx. 41.1 (W) × 33.0 (H) × 24.0 (D)
Except protruding
portion
Weight
Approx. 125 g
Excluding the cable
Housing material
Zinc alloy diecasting
