Tuning Setting Flow
7.1.2
The general flow of “Examine” and “Integrate” when using tuning are as follows.
Examination
Examine installation requirements etc., and confirm operable condition.
 Decide the scanner focus model by code resolution and
installation distance.
: Depth of Field and Focus Type

 Examine optimum installation condition without reflection etc.
using UniversalTunigTool.
: Scanned Media and Placement

 Perform tuning.
: Tuning

 Perform a test and confirm whether it is a stable reading.
: Reading Test

 Examine “require setting for operation”.
: Refer to each section
Integration
Set the scanner in the following order.
 Configure settings that are required in advance like interface
setting etc.
: Interface

 Configure “require setting for operation”.
: Refer to each section

 Perform tuning. (Caution)
: Execute Tuning

 Set additional codes if necessary.*
: Setting of Readable Codes
(Caution) Since tuning adjustment value differs for each scanner, tuning needs to be performed for
each scanner.
* The additional code needs to be same distance and reflectance.
