Opticon NLV-5201 - High Resolution Model (HD) Depth of Field

Chapter-2
Before Using
NLV-5201 User's Manual
13
1st
High Resolution Model (HD) Depth of Field
2.5.2
* The depth of field is the typical value measured by tilting the test chart 15° from the optical axis. (25C°)
* Refer to 11.2.2 Technical Specifications High Resolution Model (HD) Reading Depth of Field for specified value.
0
50 100
150
200
0 50
50
25
75
75
25
Code 39
Code 128
EAN/UPC
PDF417
QR Code
Data Matrix
0.076mm(3.0mil)
45 72
0.127mm(5.0mil)
35
119
0.254mm (10mil)
55
179
0.20mm (7.9mil)
159
68
0.33mm (13mil)
48
200
0.127mm (5.0mil)
39
109
0.254mm (10mil)
46
154
0.127mm (5.0mil)
43
91
0.381mm (15mil)
24
180
0.127mm (5.0mil)
48
78
0.254mm (10mil)
139
28
[ Unit：mm ]
