Opticon NLV-5201 - Technical Specifications

Chapter-11
Appendix
NLV-5201 User's Manual
145
1st
Technical Specifications
11.2.2
Standard Model Reading Characteristics
Item
Specification
Notes
Standard model
Minimum
resolution
Code 39
GS1 DataBar
Composite Code
PDF417
QR Code
Data Matrix
: 0.1 mm
: 0.169 mm
: 0.169 mm
: 0.169 mm
: 0.169 mm
: 0.169 mm
OPTOELECTRONICS
test chart
Curvature
Radius ≥ 20 mm (UPC12)
Barcode
width
Possible to read:
Width 100 mm Code 39 Resolution 0.2 mm
(DOF: 168 mm)
Motion
tolerance
Possible to read:
UPC 100% moving at 2.54 m/s (DOC: 128 mm)
Standard Model Reading Depth of Field
(TA = 25°C)
Resolution
mm (mil)
Code
PCS (MRD)
Guaranteed Value (mm)
Typical Value (mm)
Near
Far
Near
Far
0.127 mm
(5 mil)
Code 39
0.9
(0.8)
64
110
53
126
0.254 mm
(10 mil)
Code 39
0.9
(0.8)
62
209
52
237
0.508 mm
(20 mil)
Code 39
0.9
(0.8)
84
371
69
433
0.2 mm
(7.9 mil)
Code 128
0.9
(0.8)
77
165
62
191
0.33 mm
(13 mil)
UPC/EAN
0.9
(0.8)
62
248
50
291
0.169 mm
(6.7 mil)
PDF417
0.9
(0.8)
57
129
49
146
0.254 mm
(10 mil)
PDF417
0.9
(0.8)
53
183
42
211
0.169 mm
(6.7 mil)
QR Code
0.9
(0.8)
73
97
60
111
0.381 mm
(15 mil)
QR Code
0.9
(0.8)
27
214
22
250
0.169 mm
(6.7 mil)
Data Matrix
0.9
(0.8)
75
101
62
116
0.254 mm
(10 mil)
Data Matrix
0.9
(0.8)
55
149
43
173
* The depth of field is a determined while using the OPTOELECTRONICS test chart PCS 0.9, without specular
reflection and at room temperature and room humidity.
* Refer to 2.5.1 Standard Model (SR) Depth of Field for drawing.
