Basic Commands
3.3
Following are the basic commands for the scanner.
ACK/NAK for Serial Commands 3.3.1
When "ACK/NAK for serial commands" is enabled, the scanner will send an ACK (0x06) when a
command is received and accepted, and a NAK (0x15) when a command is rejected.
Item
Command
Description
Default
ACK/NAK
WC
Enable ACK/NAK for serial commands
WD
Disable ACK/NAK for serial commands

Diagnostic Commands 3.3.2
These commands can be used to get diagnostics information from the scanner.
Item
Command
Description
Remark
Diagnostics
Z1
Transmit software version
ZA
Transmit ASCII printable string
YV
Transmit ASCII control string
Enable/Disable 2D Menu Code 3.3.3
To enable/disable the processing of 2D menu codes, use the settings below.
Setting ‘Disable 2D menu codes’ is recommended when 2D menu codes are not used.
Item
Command
Description
Default
Enable/Disable
2D menu code
[D1Y
Enable 2D menu code

[D1Z
Disable 2D menu code*
* Indicates reading 2D menu code as normal 2D code. Therefore, 2D menu code data will be output when reading
success.
Enable/Disable 1D Menu Code 3.3.4
To enable/disable the decoding of 1D menu codes, use the settings below.
Setting ‘Disable 1D menu codes’ is recommended when 1D menu codes are not used.
Item
Command
Description
Default
Enable/Disable
1D menu code
[DFB
Q0
Q1
Enable when using trigger key.

Q0
Q0
Disable when using trigger key.*
Q1
Q1
Enable when using external trigger signal.
Q1
Q0
Disable when using external trigger signal.*

Q2
Q1
Enable when using command trigger or auto trigger.
Q2
Q0
Disable when using command trigger or auto trigger.*

* Indicates that 1D menu code reading is prohibited.
