Opticon NLV-5201 - Read Time Setting

Chapter-6
Reading and Timing
NLV-5201 User's Manual
70
1st
Read Time Setting
6.1.4
Read time setting sets the reading time of 1 reading operation. After trigger signal is on, or when the
readout command “Z” is sent, readout operation starts. If no data outputted within the specified time,
the readout operation stops.
Item
Command
Description
Default
Read time setting
Y0
Trigger signal synchronization or “Z” “Y” command
control

Y1
1 second
Y2
2 seconds
Y3
3 seconds
Y4
4 seconds
Y5
5 seconds
Y6
6 seconds
Y7
7 seconds
Y8
8 seconds
Y9
9 seconds
YL
Read time infinite
YM
Read time 10 times
* When auto trigger with “Y0”, read time is automatically set by the image processing.
The extended read time can be set with numerical parameters by inputting the command followed by a
4-digit numerical command in unit of 10 ms.
Item
Command
Description
Default
(effective
range)
Extended read time
numerical setting
[DF7
Qa
Qb
Qc
Qd
Setting of extended read time
Synchronize
with trigger
(1000a+100b+10c+d)
[x10ms]
Example when read time 500ms)
<Esc>[DF7Q0Q0Q5Q0<CR>
0050 x 10 = 500 ms
*Setting is in unit of 10 ms.
