2 Technical data
The following information are the dimensions and indications of weight and the manufacturer‘s
approved machine data.
2.1 Electrical connection
BF20V BF20L │ BF20LD
Motor 230 V / 50Hz / 850 W
2.2 Drilling-milling capacity
BF20V BF20L │ BF20LD
Drilling capacity [mm] max. Ø 16
Milling capacity of end-mill cutter [mm] max.
Ø 20
Milling capacity of inserted tooth cutter [mm] max.
Ø63
Throat [mm] 185
2.3 Spindle seat
BF20V BF20L │ BF20LD
Spindle seat MT 2 / M10
Spindle sleeve stroke [mm] 50 mm
2.4 Drilling and milling head
BF20V BF20L │ BF20LD
Swivelling + / - 90°
Reduction stages 2
Z axis travel [mm] 280
2.5 Cross table
BF20V BF20L │ BF20LD
Table length [mm] 500 700
Table width [mm] 180
X-axis travel [mm] 280 480
Y-axis travel [mm] 175
T - slot size / distance [mm] 12 / 63
Max. load [kg] 50 40
2.6 Dimensions
BF20V BF20L │ BF20LD
Height [mm] 935
Depth [mm] 565 565
Width [mm] 745 950
Total weight [kg] 103 112 114
2.7 Working area
BF20V BF20L │ BF20LD
Height [mm] 2000
Depth [mm] 2200
Width [mm] 1500
2.8 Speeds
BF20V BF20L │ BF20LD
Gear stage slow [min
-1
] 90 - 1480
