4.2.1 Control panel
Img.4-2: control panel, front view
Img.4-3: Control panel, back
Pos. Designation Pos. Designation
10 Clamping screw of spindle sleeve 11 Digital display speed
12 EMERGENCY-STOP 13 Speed control
14 Push button Start 15 Change-over switch
16 Machine lighting 17 Push button Stop
18 Digital display fine crossfeed of spindle sleeve 19 Main switch
20 Control 21 230V voltage supply
22 Fuse 23 Illumination
10
13
14
17
23
11
12
15
18
19
20
21
20
