Speed axis parameter
Three-level menu, press "PROG" key to enter to modify the speed axis parameter.
5.4.3 Parameter setting of X-axis
Sensor
Setting of sensor type: Press "PROG" to enter the menu, the digital sensor types MS100,MS200,MS500
are selectable.
Setting resolution
Press "PROG" key to enter and choose.
For sensor type MS 100, there are 5 possibilities to choose from 1µm
ǀ 2µm ǀ 5µm ǀ 10µm ǀ 50µm
For sensor type MS 200, there are 4 possibilities to choose from. 2µm
ǀ 5µm ǀ 10µm ǀ 50µm
For sensor type MS 500, there are 3 possibilities to choose from. 5µm
ǀ 10µm ǀ 50µm
Setting counting direction
Press the "PROG" key to enter the menu. “+/-“ as a select.
Setting display mode
Press the "PROG" key to enter the menu. "On / Off" as a select.
Linear error compensation
Press the "PROG" key to enter the menu, use ↑ ↓ ← → keys to modify, then press the "PROG" key to exit.
Save and Exit
Saving new parameters, press the "PROG" key to confirm, then return to section 5.4.2
INFORMATION
The parameter setting of Y, Z-axis is the same as X-axis.
