 Place the drilling-milling machine on the provided underground.
 Fix the drilling-milling machine in the provided through-holes on the machine foot.
WARNING!
The condition of the underground and the fixing type of the machine foot to the
underground must be in a way that it can bear the loads of the drilling-milling machine.
The underground must be level. Check if the underground of the drilling-milling machine
is level using a spirit level.
Fix the foot of the drilling-milling machine to the substructure with the provided through-holes.
When using an optionally available machine substructure, it also needs to be anchored safely
and firmly. We recommend you to use shear connector cartridges resp. heavy-duty anchors.
 "Dimensions, installation plan BF20V“ on page 19,
 "Dimensions, installation plan BF20L │ BF20LD“ on page 20,
 "Installation plan of optional substructure“ on page 21.
3.4 First commissioning
ATTENTION!
Before commissioning the machine check all screws, fixtures resp. safety devices and
tighten up the screws if necessary!
WARNING!
Risk by using improper tool holders or operating them at inadmissible speeds.
Only use the tool holders (e.g. drill chuck) which were delivered with the machine or
which are offered as optional equipment by OPTIMUM.
Only use tool holders in the intended admissible speed range.
It is only allowed to modify tool holding fixtures in compliance with the
recommendations of
OPTIMUM or the manufacturer of the clamping device.
WARNING!
When first commissioning the drilling-milling machine by inexperienced staff you
endanger people and the machine.
We do not take any liability for damages caused by incorrectly performed commission-
ing.
 "Qualification of personnel“ on page 11
3.4.1 Power supply
CAUTION !
Lay the connection cable of the machine so that a stumble of persons is prevented.
 Connect the electrical supply cable.
 Check the fusing (fuse) of your electrical supply according to the technical instructions
regarding the total connected power of the drilling-milling machine.
3.4.2 Cleaning and lubricating
 Remove the anti-corrosive agents on the drilling-milling machine which had been applied
for transportation and storage. Therefore, we recommend you to use paraffin.
 Do not use any solvents, cellulose thinner or any other cleaning agents which might affect
the coating of the drilling-milling machine when cleaning the machine. Observe the indica-
tions and notes of the manufacturer for cleaning agents.
 Oil all blank machine parts using an acid-free lubricating oil.
