Version 4.0.2 dated 2019-4-3 Page 49Translation of the original instructions
D210 | BF16 | BF20V | BF20L | D250 | GB
Adjusting_control-
OPTIMUM
MASCHINEN - GERMANY
®
Measuring range min. 1 M Ohm
Potentiometer
Setting value
Only approximate value,
perform setting via
speed control
.
Measuring points
measuring point 3
+ 12V
measuring point 1
measuring point 2
measuring point 4
