Table 3-3 (Cont.) Customer Network Configuration Page
Customer Details Field Description
Gateway Sets the IP address for the gateway.
Client or Backup Network Format Selects the Ethernet cards, based on cable
type.
Options prior to X7-2:
•
1/10 GbE Base-T
when using copper
cables
•
10 GbE Optical
when using fiber optic
cables
Note: The Admin network uses 1/10 GbE
Base-T Ethernet cables. The network format
for the private network is InfiniBand.
Options for X7-2 Systems:
On X7-2 systems, there are 3 available
formats for client and backup networks.
• RJ45/SFP28 Combined on Motherboard
– RJ45 10 GBit
– SFP28 10 GBit
– SFP28 25GBit
• SFP28 PCI Dual Port Card
– SFP28 10 GBit
– SFP28 25GBit
• RJ45 PCI Quad Port Card (extra cost
option)
Options for X7-8 Systems:
On X7-8 systems, there are 2 available
formats for client and backup networks:
• RJ45 on Motherboard
• SFP28 PCI Dual Port Cards
– SFP28 10 GBit
– SFP28 25GBit
If you select one of the SFP28 network types
on X7-2 or X7-8 systems, you must
additionally specify whether to use 10 GBit or
25 GBit connections.
Available Network Enables an additional subnet for backup,
replication, or data recovery.
Note: This subnet is optional.
Advanced Options Click this button to display VLAN options.
