Table 1-43 (Cont.) IP Address Requirements for Oracle Exadata Storage
Expansion Rack
Type of Oracle Exadata Storage Expansion
Rack
Network Requirements
Oracle Exadata Storage Expansion X3-2 Full
Rack
Total of 60 IP addresses (42 for the
management network, and 18 for the private
InfiniBand network)
• 18 IP addresses for administration, one
per Exadata Storage Server
• 18 IP addresses for ILOM, one per
Exadata Storage Server
• 4 IP addresses for switches (3 for
InfiniBand, and 1 for Ethernet)
• 2 IP addresses for monitoring electric
current of the PDUs
• 18 IP addresses for the private InfiniBand
network
Oracle Exadata Storage Expansion X3-2 Half
Rack
Total of 33 IP addresses (24 for the
management network, and 9 for the private
InfiniBand network)
• 9 IP addresses for administration, one per
Exadata Storage Server
• 9 IP addresses for ILOM, one per
Exadata Storage Server
• 4 IP addresses for switches (3 for
InfiniBand, and 1 for Ethernet)
• 2 IP addresses for monitoring electric
current of the PDUs
• 9 IP addresses for the private InfiniBand
network
Oracle Exadata Storage Expansion X3-2
Quarter Rack
Total of 17 IP addresses (13 for the
management network, and 4 for the InfiniBand
network)
• 4 IP addresses for administration, one per
Exadata Storage Server
• 4 IP addresses for ILOM, one per
Exadata Storage Server
• 3 IP addresses for switches (2 for
InfiniBand, and 1 for Ethernet)
• 2 IP addresses for monitoring electric
current of the PDUs
• 4 IP addresses for the private InfiniBand
network
1.9 Ensuring Site is Ready
Before Oracle Exadata Rack is delivered to the site, the following tasks must be
performed to ensure the site is ready:
Chapter 1
Ensuring Site is Ready
1-75
