3.2.8 InfiniBand Network Configuration Page
The InfiniBand network is the private network between database servers and storage
servers. The following table lists the InfiniBand network fields.
Note:
Sample name formats are based on the prefix entered on the Customer
Details page. To modify the name formats, click Modify.
Table 3-8 InfiniBand Network Page
InfiniBand Network Field Description
Starting IP Address for Pool Assigns the starting IP address for the private
network port.
Note: The pool should consist of consecutive
IP addresses. If consecutive IP addresses are
not available, then specific IP addresses can
be modified during the configuration process.
Pool Size Defined by the hardware selection.
Ending IP Address for Pool Defined by the starting IP address and the
pool size.
Related Topics:
• Overview of Network Requirements (page 2-1)
3.2.8.1 Modifying the Default InfiniBand Network Names
The following table lists the InfiniBand network format mask fields.
Note:
The percent signs (%) in the names are replaced by the numbers entered into
the Starting ID fields.
Table 3-9 Private (IB) Network Format Masks Page
Private (IB) Network Format Masks Field Description
Compute Private Name Sets the InfiniBand access name for the
database servers.
Note: The name contains alphanumeric
characters.
This field cannot be empty.
Chapter 3
OEDA Graphical User Interface
3-15
