Table 1-11 (Cont.) Environmental Requirements for Oracle Exadata Storage
Expansion Rack X5-2
Environmental
Component
Oracle Exadata
Storage Expansion
X5-2 Full Rack
Oracle Exadata
Storage Expansion
X5-2 Half Rack
Oracle Exadata
Storage Expansion
X5-2 Quarter Rack
Cooling • Extreme Flash
drives
Maximum: 43,765
BTU/hour (46,170
kJ/hour)
Typical: 30,635
BTU/hour (32,320
kJ/hour)
• High capacity
drives
Maximum: 42,670
BTU/hour (45,020
kJ/hour)
Typical: 29,870
BTU/hour (31,515
kJ/hour)
• Extreme Flash
drives
Maximum: 19,880
BTU/hour (20,970
kJ/hour)
Typical: 13,915
BTU/hour (14,680
kJ/hour)
• High capacity
drives
Maximum: 22,950
BTU/hour (24,210
kJ/hour)
Typical: 16,065
BTU/hour (16,950
kJ/hour
• Extreme Flash
drives
Maximum: 12,362
BTU/hour (13,042
kJ/hour)
Typical: 8,654
BTU/hour (9,129
kJ/hour)
• High capacity
drives
Maximum: 12,212
BTU/hour (12,884
kJ/hour)
Typical: 8,548
BTU/hour (9,019
kJ/hour)
Air flow front-to-back
(subject to actual data
center environment)
• Extreme Flash
drives
Maximum:
Approximately
2,030 CFM
Typical:
Approximately
1,420 CFM
• High capacity
drives
Maximum:
Approximately
1,975 CFM
Typical:
Approximately
1,385 CFM
• Extreme Flash
drives
Maximum:
Approximately
920 CFM
Typical:
Approximately
645 CFM
• High capacity
drives
Maximum:
Approximately
1,065 CFM
Typical:
Approximately
745 CFM
• Extreme Flash
drives
Maximum:
Approximately
565 CFM
Typical:
Approximately
396 CFM
• High capacity
drives
Maximum:
Approximately
572 CFM
Typical:
Approximately
401 CFM
IP Addresses 44 for Ethernet
network, assuming
single cluster
38 for InfiniBand
network
24 for Ethernet
network, assuming
single cluster
18 for InfiniBand
network
13 for Ethernet
network, assuming
single cluster
8 for InfiniBand
network
Network drops Minimum of 1 network
drop
Minimum of 1 network
drop
Minimum of 1 network
drop
External connectivity 12 InfiniBand ports 12 InfiniBand ports 12 InfiniBand ports
Chapter 1
General Environmental Requirements
1-21
