Table 3-16 (Cont.) Oracle Configuration Manager Configuration Page
Oracle Configuration Manager Field Description
HTTP Proxy Host Enables the HTTP proxy server to connect to
Oracle. The proxy server may be between the
following:
• Database servers and Oracle (applicable
when you do not have Oracle Support
Hub)
• Database servers and Support Hub
(applicable when you have only Oracle
Support Hub)
• Support Hub and Oracle
If passwords are needed, then provide them
during installation.
Example:
[proxy_user@]proxy_host[:proxy_port]
The
proxy_host
and
proxy_port
entries are
optional.
Proxy Port Sets the HTTP proxy server port number. The
default is
80
.
HTTP Proxy requires authentication Enables HTTP proxy authentication.
HTTP Proxy User Sets the HTTP proxy server user name.
Related Topics:
• Oracle Technical Support Policies
• Oracle Configuration Manager Companion Distribution Guide
3.2.19 Grid Control Agent Configuration Page
Oracle Enterprise Manager Grid Control is used to monitor Oracle Exadata Rack.
Oracle Enterprise Manager Grid Control installs agents on the database servers and
points the agents to an existing Oracle Enterprise Manager Grid Control environment,
or installs a new Oracle Enterprise Manager Grid Control infrastructure on a separate
host.
Table 3-17 (page 3-29) lists the Oracle Enterprise Manager Grid Control
configuration options.
Table 3-17 Oracle Enterprise Manager Grid Control Configuration Page
Oracle Enterprise Manager Grid Control
Field
Description
Enable Oracle Enterprise Manager Grid
Control Agent
Enables Oracle Enterprise Manager Grid
Control to monitor the rack.
EM Home Base Location Sets the base directory for the agents installed
on the database servers.
Chapter 3
OEDA Graphical User Interface
3-29
