Table 3-4 Administration Network Page
Administration Network Field Description
Starting IP Address for Pool Assigns the starting IP address for the
administration network port of the servers, and
switches.
Note: These addresses are also assigned to
the ILOM ports on the database and storage
servers.
The pool should consist of consecutive IP
addresses. If consecutive IP addresses are
not available, then specific IP addresses can
be modified during the configuration process.
Pool Size Defined by the hardware selection.
Ending IP Address for Pool Defined by the starting IP address and the
pool size.
Is the default gateway for database servers Specifies that the gateway IP address is the
default gateway for the database servers.
Note: This option is not usually selected for
the database servers.
Defines the Hostname for the Compute Nodes Select this option if the adapter name defines
the host names for the database servers.
Note: This option is usually selected for the
database servers.
Related Topics:
• Overview of Network Requirements (page 2-1)
3.2.6.1 Modifying the Default Administration Network Host Names
Default administration network host names are usually changed to meet corporate
naming standards or compatibility with existing systems. Table 3-5 (page 3-12) lists
the administration network format mask fields.
Note:
• Oracle recommends using the same starting IDs for the servers and
server ILOMs.
• All fields must be filled in.
• The percent signs (%) in the names are replaced by the numbers entered
into the Starting ID fields.
Chapter 3
OEDA Graphical User Interface
3-11
