Table 1-13 (Cont.) Environmental Requirements for Oracle Exadata Storage
Expansion Rack X3-2
Environmental
Component
Oracle Exadata
Storage Expansion
X3-2 Full Rack
Oracle Exadata
Storage Expansion
X3-2 Half Rack
Oracle Exadata
Storage Expansion
X3-2 Quarter Rack
IP Addresses 42 for Ethernet
network, assuming
single cluster
18 for InfiniBand
network
24 for Ethernet
network, assuming
single cluster
9 for InfiniBand
network
13 for Ethernet
network, assuming
single cluster
4 for InfiniBand
network
Network drops Minimum of 1 network
drop
Minimum of 1 network
drop
Minimum of 1 network
drop
External connectivity 12 InfiniBand ports 12 InfiniBand ports 12 InfiniBand ports
1.1.16 General Environmental Requirements for Oracle Exadata
Storage Expansion Rack with Exadata Storage Server with Sun Fire
X4270 M2 Servers
The environmental requirements for Oracle Exadata Storage Expansion Rack with
Exadata Storage Server with Sun Fire X4270 M2 Servers depend on the size of the
system. Table 1-14 (page 1-25) shows the general environmental requirements for
each type of Oracle Exadata Storage Expansion Rack with Exadata Storage Server
with Sun Fire X4270 M2 Servers.
Table 1-14 Environmental Requirements for Oracle Exadata Storage Expansion
Rack with Exadata Storage Server with Sun Fire X4270 M2 Servers
Environmental
Component
Oracle Exadata
Storage Expansion
Full Rack
Oracle Exadata
Storage Expansion
Half Rack
Oracle Exadata
Storage Expansion
Quarter Rack
Weight 917.6 kg (2023 lbs) 578.3 kg (1275 lbs) 396.8 kg (875 lbs)
Acoustic levels 83 db(A) 82 db(A) 81 db(A)
Power Maximum: 12.6 kW
(12.9 kVA)
Typical: 8.8 kW (9.0
kVA) (varies based on
application load)
Maximum: 6.9 kW
(7.1 kVA)
Typical: 4.8 kW (5.0
kVA) (varies based on
application load)
Maximum: 3.4 kW
(3.5 kVA)
Typical: 2.4 kW
(2.5kVA) (varies
based on application
load)
Cooling Maximum: 43,000
BTU/hour (45,400 kJ/
hour)
Typical: 30,100 BTU/
hour (31,800 kJ/hour)
Maximum: 23,600
BTU/hour (24,900 kJ/
hour)
Typical: 16,500 BTU/
hour (17,400 kJ/hour)
Maximum: 11,600
BTU/hour (12,250 kJ/
hour)
Typical: 8,100 BTU/
hour (8,600 kJ/hour)
Chapter 1
General Environmental Requirements
1-25
