Table 1-43 IP Address Requirements for Oracle Exadata Storage Expansion
Rack
Type of Oracle Exadata Storage Expansion
Rack
Network Requirements
Oracle Exadata Storage Expansion X4-2 Full
Rack and later
Up to a total of 78 IP addresses (42 for the
management network, and up to 36 for the
private InfiniBand network)
• 18 IP addresses for administration, one
per Exadata Storage Server
• 18 IP addresses for ILOM, one per
Exadata Storage Server
• 4 IP addresses for switches (3 for
InfiniBand, and 1 for Ethernet)
• 2 IP addresses for monitoring electric
current of the PDUs
• Up to 36 IP addresses for the private
InfiniBand network
Oracle Exadata Storage Expansion X4-2 Half
Rack
Up to a total of 42 IP addresses (24 for the
management network, and up to 18 for the
private InfiniBand network)
• 9 IP addresses for administration, one per
Exadata Storage Server
• 9 IP addresses for ILOM, one per
Exadata Storage Server
• 4 IP addresses for switches (3 for
InfiniBand, and 1 for Ethernet)
• 2 IP addresses for monitoring electric
current of the PDUs
• Up to 18 IP addresses for the private
InfiniBand network
Oracle Exadata Storage Expansion X4-2
Quarter Rack
Up to a total of 21 IP addresses (13 for the
management network, and up to 8 for the
private InfiniBand network)
• 4 IP addresses for administration, one per
Exadata Storage Server
• 4 IP addresses for ILOM, one per
Exadata Storage Server
• 3 IP addresses for switches (2 for
InfiniBand, and 1 for Ethernet)
• 2 IP addresses for monitoring electric
current of the PDUs
• Up to 8 IP addresses for the private
InfiniBand network
Chapter 1
Network Connection and IP Address Requirements for Oracle Exadata Storage Expansion Rack
1-74
