Access Route
Considerations
Yes No N/A Comment
Has the access
route been
checked for
clearances of the
rack, in
particular, the
minimum width
and height
requirements for
all doors on the
route?
Dimensions of
the packaged
rack:
• Height: 2159
mm (85
inches)
• Width: 1219
mm (48
inches)
• Depth: 1575
mm (62
inches)
Dimensions of
the unpackaged
rack:
• Height: 1998
mm (78.66
inches)
• Width: 600
mm with side
panels
(23.62
inches)
• Depth 1200
mm (47.24
inches)
Are there any
stairs, ramps, or
thresholds that
are of concern? If
yes, then provide
details.
Are all access
route incline
angles within the
permitted range
(6 degrees)?
Is the access
route free of any
obstacles that
would expose the
equipment to
shock?
Appendix A
Access Route Checklist
A-7
