Install the Cable Management Arm
Callout Description
1 Connector A
2 Front slide bar
3 Velcro straps (6)
4 Connector B
5 Connector C
6 Connector D
7 Slide-rail latching bracket
(used with connector D)
8 Rear slide bar
9 Oracle Server X6-2 cable
covers
10 Oracle Server X6-2L cable
covers
2.
Ensure that the correct cable covers for your server are installed on the CMA.
■
The Oracle Server X6-2 (1U system) uses the flat cable covers.
■
The Oracle Server X6-2L (2U system) uses the round cable covers.
Note - The CMA ships with three, flat cable covers installed. If you are going to install the
CMA on a Oracle Server X6-2L, you need to remove the flat cable covers and install the round
cable covers.
3.
Ensure that the six Velcro straps are threaded into the CMA.
Note - Ensure that the two Velcro straps located on the front slide bar are threaded through the
opening in the top of the slide bar as shown in the illustration in Step 1. This prevents the Velcro
straps from interfering with the expansion and contraction of the slide bar when the server is
extended out of the rack and returned into the rack.
4.
To make it easier to install the CMA, extend the server approximately 13 cm (5
inches) out of the front of the rack.
5.
Take the CMA to the back of the equipment rack, and ensure that you have
adequate room to work at the back of the server.
Note - References to “left” or “right” in this procedure assume that you are facing the back of
the equipment rack.
Installing the Server Into a Rack 57
