Installing a ZS4-4 or ZS3-4 Controller
This section contains installation procedures for the ZS4-4 or ZS3-4 controller.
Before beginning installation, see “Installation Prerequisites and Hardware
Overviews” on page 11.
Use the following procedures to install a ZS4-4 or ZS3-4 controller:
■
“Installing the Slide Rails onto a ZS4-4 or ZS3-4” on page 127
■
“Installing the Slide Rails into the Rack for a ZS4-4 or ZS3-4” on page 128
■
“Installing a ZS4-4 or ZS3-4 onto the Rack Slide Rails” on page 130
■
“Installing a ZS4-4 or ZS3-4 Cable Management Arm” on page 133
Installing the Slide Rails onto a ZS4-4 or ZS3-4
Use the following procedure to install the slide rails onto a ZS4-4 or ZS3-4 controller.
Note - The slide rails can be used with either 9.5-mm square or M6 round mounting hole racks.
1.
Position a mounting bracket against the chassis so that the slide-rail lock is at
the front of the chassis, and the five keyed openings on the mounting bracket
are aligned with the five locating pins on the side of the chassis.
Installing a ZS4-4 or ZS3-4 Controller 127
